Curved 2D Welded Double Horizontal Wire Fence For Factory 50*200mm

Product Name : Double Wire Fence

Key Word : Double Loop Wire Fence

Material : Heavy low carbon wire, stainless steel wire

Wire Diameter : 8/6/8mm, 6/5/6mm, 5/4/5mm or customized

Mesh Hole : 50*200mm / 50*150mm / 50*100mm or customized

Panel Height : From 0.4m - 3.03m

Panel Width : 2.0m, 2.5m as standard

Features : Corrosion, abrasion and pressure resistance.

Application : Airport,private place,railway Security fence

Surface Treatment : Galvanized then PVC coating / hot dip galvanized after welded

Certificate : ISO9001, SGS, etc.

Sample : For Free

Brand Name : LJ

Model Number : LJ-04

Certification : ISO9001,SGS

Place of Origin : Hebei Province,China

MOQ : 30 pcs

Price : $13.5-29.5/pc

Payment Terms : T/T,L/C

Supply Ability : 5000pcs/week

Delivery Time : 7-15 work day

Packaging Details : steel pallet

Contact Now

Curved 2D Welded Double Horizontal Wire Fence For Factory 50*200mm

Description of Double Wire Fence

Double wire fence—also known as welded double horizontal wire fence or twin wire fence,which is made from mild or stainless steel—is a high-performance fencing option renowned for its exceptional stability and versatility. It is made from mild or stainless steel. With a special structure—double horizontal wire welded to single vertical wire, double wire fence is more endurable and stable than common wire fence. Because of its features of corrosion resistant, high rigidity, and high security, it is widely used as fencing barrier for factories, administrative buildings, supermarkets, schools, courts, parks, playground facilities, and so on.

Double Wire Fence offered in versatile specifications—wire diameter combinations (e.g., 8mm×2+6mm×1, 7mm×2+5mm×1) and mesh sizes (typically 50×200mm)—it delivers exceptional tensile strength to thwart intrusion and unauthorized entry. Beyond security, its clean, uniform grid design offers clear visibility while complementing diverse settings: gardens, residential complexes, industrial parks, schools, stadiums, and commercial properties.

Specifications of Double Wire Fence

Double wire fence
Panel Height x Width mm	Mesh Size mm	Wire diameter			Post Height
Panel Height x Width mm	Mesh Size mm	Wire dia mm	Wire dia mm	Wire dia mm	Post Height
630 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	1100
830 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	1300
1030 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	1500
1230 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	1700
1430 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	1900
1630 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	2100
1830 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	2400
2030 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	2600
2230 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	2800
2430 x 2500	50 x 200	8x2 + 6	6x2 + 5	6x2 + 4	3000

Features of Double Wire Fence

Enhanced Structural Stability: Two parallel horizontal wires welded with vertical wires form a rigid framework, resisting deformation, impact, and external pressure better than standard mesh fences.
Premium Material & Durability: Made of mild steel, carbon steel, or stainless steel, with hot-dip galvanization or polyester powder coating for strong corrosion and rust resistance, ensuring long service life in harsh weather.
Flexible Specifications: Available in various wire diameter combinations (e.g., 6mm×2+5mm×1, 8mm×2+6mm×1) to meet different security and load-bearing requirements.
Aesthetic & Versatile Design: Sleek, uniform appearance blends with landscaping, complementing both functional and decorative needs without being obtrusive.
Easy Installation & Low Maintenance: Lightweight yet sturdy, compatible with square or peach posts for quick assembly; no frequent repairs needed, just occasional cleaning.
Reliable Security Performance: High tensile strength deters trespassing, climbing, and unauthorized access, providing robust protection for properties.

Application of Double Wire Fence

· Airports.

· Railways.

· Industrial places.

· Schools.

· Parks.

· Gardens.

· Farms.

· Yard.

· Private residences.

· Playgrounds.

· Football or basketball fields.
